手把手教你珍稀动物检测

# 解压原始数据集!unzip /home/aistudio/data/data300189/animals.zip -d data/

import osimport zipfileimport randomimport jsonimport paddleimport sysimport numpy as npfrom PIL import Imageimport paddleimport matplotlib.pyplot as plt

'''
参数配置
'''train_parameters = {    "input_size": [3, 64, 64],                                #输入图片的shape
    "class_dim": -1,                                          #分类数
    "src_path":"data/data300189/animals.zip",                    #原始数据集路径
    "target_path":"/home/aistudio/data/animals/animals/",                     #要解压的路径
    "train_list_path": "/home/aistudio/data/train.txt",       #train.txt路径
    "eval_list_path": "/home/aistudio/data/eval.txt",         #eval.txt路径
    "readme_path": "/home/aistudio/data/readme.json",         #readme.json路径
    "label_dict":{},                                          #标签字典
    "num_epochs": 20,                                          #训练轮数
    "train_batch_size": 64,                                   #训练时每个批次的大小
    "learning_strategy": {                                    #优化函数相关的配置
        "lr": 0.01                                          #超参数学习率
    }
}

def get_data_list(target_path,train_list_path,eval_list_path):
    '''
    生成数据列表
    '''
    #存放所有类别的信息
    class_detail = []    #获取所有类别保存的文件夹名称
    data_list_path=target_path
    class_dirs = os.listdir(data_list_path)
    #总的图像数量
    all_class_images = 0
    #存放类别标签
    class_label=0
    #存放类别数目
    class_dim = 0
    #存储要写进eval.txt和train.txt中的内容
    trainer_list=[]
    eval_list=[]    #读取每个类别
    for class_dir in class_dirs:        if class_dir != ".DS_Store":   #".DS_Store" 是一个特定的文件名，通常在 macOS 系统中出现。这是 macOS 系统用于存储文件夹的自定义属性的隐藏文件。
            class_dim += 1
            #每个类别的信息
            class_detail_list = {}
            eval_sum = 0
            trainer_sum = 0
            #统计每个类别有多少张图片
            class_sum = 0
            #获取类别路径
            path = data_list_path  + class_dir            # 获取所有图片
            img_paths = os.listdir(path)            for img_path in img_paths:                                  # 遍历文件夹下的每个图片
                name_path = path + '/' + img_path                       # 每张图片的路径
                if class_sum % 8 == 0:                                  # 每8张图片取一个做验证数据
                    eval_sum += 1                                       # test_sum为测试数据的数目
                    eval_list.append(name_path + "\t%d" % class_label + "\n")                else:
                    trainer_sum += 1
                    trainer_list.append(name_path + "\t%d" % class_label + "\n")#trainer_sum测试数据的数目
                class_sum += 1                                          #每类图片的数目
                all_class_images += 1                                   #所有类图片的数目

            # 说明的json文件的class_detail数据
            class_detail_list['class_name'] = class_dir             #类别名称
            class_detail_list['class_label'] = class_label          #类别标签
            class_detail_list['class_eval_images'] = eval_sum       #该类数据的测试集数目
            class_detail_list['class_trainer_images'] = trainer_sum #该类数据的训练集数目
            class_detail.append(class_detail_list)
            #初始化标签列表
            train_parameters['label_dict'][str(class_label)] = class_dir
            class_label += 1

    #初始化分类数
    train_parameters['class_dim'] = class_dim
    #乱序
    random.shuffle(eval_list)    with open(eval_list_path, 'a') as f:        for eval_image in eval_list:
            f.write(eval_image)

    random.shuffle(trainer_list)    with open(train_list_path, 'a') as f2:        for train_image in trainer_list:
            f2.write(train_image)

    # 说明的json文件信息
    readjson = {}
    readjson['all_class_name'] = data_list_path                  #文件父目录
    readjson['all_class_images'] = all_class_images
    readjson['class_detail'] = class_detail
    jsons = json.dumps(readjson, sort_keys=True, indent=4, separators=(',', ': '))    print(type(jsons))    print(jsons)    with open(train_parameters['readme_path'],'w') as f:
        f.write(jsons)    print ('生成数据列表完成！')

'''
参数初始化
'''src_path=train_parameters['src_path']
target_path=train_parameters['target_path']
train_list_path=train_parameters['train_list_path']
eval_list_path=train_parameters['eval_list_path']
batch_size=train_parameters['train_batch_size']# '''# 解压原始数据到指定路径# '''# unzip_data(src_path,target_path)# '''# 划分训练集与验证集，乱序，生成数据列表# '''#每次生成数据列表前，首先清空train.txt和eval.txtwith open(train_list_path, 'w') as f:
    f.seek(0)
    f.truncate()
with open(eval_list_path, 'w') as f:
    f.seek(0)
    f.truncate()

#生成数据列表   get_data_list(target_path,train_list_path,eval_list_path)

import paddleimport paddle.vision.transforms as Timport numpy as npfrom PIL import Imageclass AnimalsDataset(paddle.io.Dataset):
    """
    7种animal数据集类的定义
    """
    def __init__(self, mode='train'):
        """
        初始化函数
        """
        self.data = []        with open('data/{}.txt'.format(mode)) as f:            for line in f.readlines():
                info = line.strip().split('\t')                if len(info) > 0:
                    self.data.append([info[0].strip(), info[1].strip()])
        self.transforms = T.Compose([
            T.Resize((64, 64)),    # 图片缩放
            T.ToTensor(),                       # 数据的格式转换和标准化、 HWC => CHW
            T.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225])
            ])
    def __getitem__(self, index):
        """
        根据索引获取单个样本
        """
        image_file, label = self.data[index]

        image = Image.open(image_file)  ##读取样本数据

        if image.mode != 'RGB':
            image = image.convert('RGB')
        image = self.transforms(image)    ##数据格式转化
        return image, np.array(label, dtype='int64')  ##封装数据和标签到元组
    def __len__(self):
        """
        获取样本总数
        """
        return len(self.data)

'''
构造数据提供器
'''train_dataset = AnimalsDataset(mode='train')
eval_dataset = AnimalsDataset(mode='eval')

print(len(train_dataset))print(type(train_dataset))

train_loader = paddle.io.DataLoader(train_dataset, batch_size=100, shuffle=True,
                                    num_workers=1,
                                    drop_last=False)print('step num:',len(train_loader))

print(len(eval_dataset))
eval_loader=paddle.io.DataLoader(eval_dataset, batch_size=100, shuffle=True,
                                    num_workers=1,
                                    drop_last=False)print('step num:',len(eval_loader))

#定义卷积网络import paddle.nn as nnimport paddle.nn.functional as F# 导入需要的包import paddleimport numpy as npfrom paddle.nn import Conv2D, MaxPool2D, Linear,BatchNorm2D,Dropout2D,Dropout## 组网# 定义 CNN 网络结构class MyCNN(paddle.nn.Layer):
    def __init__(self, num_classes=1):
        super(MyCNN, self).__init__()        # 创建卷积和池化层
        # 创建第1个卷积层
        self.conv1 = Conv2D(in_channels=3, out_channels=6, kernel_size=5)
        self.BN1=BatchNorm2D(num_features=6)
        self.max_pool1 = MaxPool2D(kernel_size=2, stride=2)        # 尺寸的逻辑：池化层未改变通道数；当前通道数为6
        # 创建第2个卷积层
        self.conv2 = Conv2D(in_channels=6, out_channels=16, kernel_size=5)
        self.BN2=BatchNorm2D(num_features=16)
        self.max_pool2 = MaxPool2D(kernel_size=2, stride=2)        # 创建第3个卷积层
        self.conv3 = Conv2D(in_channels=16, out_channels=120, kernel_size=4)
        self.BN3=BatchNorm2D(num_features=120)
        self.DP1=Dropout2D(p=0.2)        # 尺寸的逻辑：输入层将数据拉平[B,C,H,W] -> [B,C*H*W]
        # 输入size是[28,28]，经过三次卷积和两次池化之后，C*H*W等于120
        self.fc1 = Linear(in_features=120*10*10, out_features=64)
        self.DP2=Dropout(p=0.2)        # 创建全连接层，第一个全连接层的输出神经元个数为64， 第二个全连接层输出神经元个数为分类标签的类别数
        self.fc2 = Linear(in_features=64, out_features=num_classes)    # 网络的前向计算过程
    def forward(self, x):
        x = self.conv1(x)
        x=self.BN1(x)
        x = F.relu(x)
        x = self.max_pool1(x)

        x = self.conv2(x)
        x=self.BN2(x)
        x = F.relu(x)
        x = self.max_pool2(x)

        x = self.conv3(x)
        x=self.BN3(x)
        x=F.relu(x)
        x=self.DP1(x)        # 尺寸的逻辑：输入层将数据拉平[B,C,H,W] -> [B,C*H*W]
        x = paddle.reshape(x, [x.shape[0], -1])
        x = self.fc1(x)
        x = F.relu(x)
        x=self.DP2(x)
        x = self.fc2(x)        return x

import paddleimport paddle.nn as nnimport paddle.nn.functional as Ffrom paddle.nn import Conv2D, MaxPool2D, Linear, BatchNorm2D, Dropout2D, Dropout# 定义 CNN 网络结构class MyCNNWithMultiScaleFusion(paddle.nn.Layer):
    def __init__(self, num_classes=1):
        super(MyCNNWithMultiScaleFusion, self).__init__()
        # 创建卷积和池化层
        self.conv1 = Conv2D(in_channels=3, out_channels=6, kernel_size=5)
        self.BN1 = BatchNorm2D(num_features=6)
        self.max_pool1 = MaxPool2D(kernel_size=2, stride=2)

        self.conv2 = Conv2D(in_channels=6, out_channels=16, kernel_size=5)
        self.BN2 = BatchNorm2D(num_features=16)
        self.max_pool2 = MaxPool2D(kernel_size=2, stride=2)

        self.conv3 = Conv2D(in_channels=16, out_channels=120, kernel_size=4)
        self.BN3 = BatchNorm2D(num_features=120)
        self.DP1 = Dropout2D(p=0.2)        # 定义第二个卷积分支
        self.conv4 = Conv2D(in_channels=3, out_channels=16, kernel_size=3)
        self.BN4 = BatchNorm2D(num_features=16)
        self.max_pool4 = MaxPool2D(kernel_size=2, stride=2)

        self.conv5 = Conv2D(in_channels=16, out_channels=32, kernel_size=3)
        self.BN5 = BatchNorm2D(num_features=32)
        self.max_pool5 = MaxPool2D(kernel_size=2, stride=2)        # 全连接层
        self.fc1 = Linear(in_features=(120*10*10 + 32*14*14), out_features=64)  # 考虑到多尺度特征
        self.DP2 = Dropout(p=0.2)
        self.fc2 = Linear(in_features=64, out_features=num_classes)    def forward(self, x):
        # 第一个卷积分支
        x1 = self.conv1(x)
        x1 = self.BN1(x1)
        x1 = F.relu(x1)
        x1 = self.max_pool1(x1)

        x1 = self.conv2(x1)
        x1 = self.BN2(x1)
        x1 = F.relu(x1)
        x1 = self.max_pool2(x1)

        x1 = self.conv3(x1)
        x1 = self.BN3(x1)
        x1 = F.relu(x1)
        x1 = self.DP1(x1)        # 第二个卷积分支
        x2 = self.conv4(x)
        x2 = self.BN4(x2)
        x2 = F.relu(x2)
        x2 = self.max_pool4(x2)

        x2 = self.conv5(x2)
        x2 = self.BN5(x2)
        x2 = F.relu(x2)
        x2 = self.max_pool5(x2)        # 特征融合
        x1 = paddle.reshape(x1, [x1.shape[0], -1])
        x2 = paddle.reshape(x2, [x2.shape[0], -1])
        x = paddle.concat([x1, x2], axis=1)        # 全连接层
        x = self.fc1(x)
        x = F.relu(x)
        x = self.DP2(x)
        x = self.fc2(x)        return x

import paddleimport paddle.nn as nnimport paddle.nn.functional as Ffrom paddle.nn import Conv2D, MaxPool2D, Linear, BatchNorm2D, Dropout2D, Dropoutclass MyDenseCNN(paddle.nn.Layer):
    def __init__(self, num_classes=1):
        super(MyDenseCNN, self).__init__()
        # 创建卷积层和池化层
        self.conv1 = Conv2D(in_channels=3, out_channels=6, kernel_size=5)
        self.BN1 = BatchNorm2D(num_features=6)
        self.max_pool1 = MaxPool2D(kernel_size=2, stride=2)

        self.conv2 = Conv2D(in_channels=6 + 3, out_channels=16, kernel_size=5)
        self.BN2 = BatchNorm2D(num_features=16)
        self.max_pool2 = MaxPool2D(kernel_size=2, stride=2)

        self.conv3 = Conv2D(in_channels=16 + 6 + 3, out_channels=120, kernel_size=4)
        self.BN3 = BatchNorm2D(num_features=120)
        self.DP1 = Dropout2D(p=0.2)        # 初始化全连接层，待定输入特征数
        self.fc1 = None  # 先设为None，后面会动态定义
        self.DP2 = Dropout(p=0.2)
        self.fc2 = Linear(in_features=64, out_features=num_classes)    def forward(self, x):
        x1 = F.relu(self.BN1(self.conv1(x)))
        x1_pool = self.max_pool1(x1)        # 调整x2输入大小
        x2_input = paddle.concat([x, F.interpolate(x1_pool, size=x.shape[2:])], axis=1)
        x2 = F.relu(self.BN2(self.conv2(x2_input)))
        x2_pool = self.max_pool2(x2)        # 调整x3输入大小
        x3_input = paddle.concat([x, F.interpolate(x1_pool, size=x.shape[2:]), F.interpolate(x2_pool, size=x.shape[2:])], axis=1)
        x3 = F.relu(self.BN3(self.conv3(x3_input)))
        x3_dropped = self.DP1(x3)        # 打印x3_dropped的形状
        # print(f"x3_dropped shape: {x3_dropped.shape}")
        # 动态计算全连接层输入特征数
        x_flat = paddle.reshape(x3_dropped, [x3_dropped.shape[0], -1])
        in_features_fc1 = x_flat.shape[1]  # 动态获取特征数
        if self.fc1 is None:  # 如果fc1未初始化
            self.fc1 = Linear(in_features=in_features_fc1, out_features=64)

        x_fc1 = F.relu(self.fc1(x_flat))
        x_fc1_dropped = self.DP2(x_fc1)

        x_out = self.fc2(x_fc1_dropped)        return x_out

from paddle.vision.models import resnet50# 设置设备device = paddle.set_device('gpu:0' if paddle.is_compiled_with_cuda() and paddle.cuda.is_available() else 'cpu')

import paddlefrom paddle.vision.models import resnet50,vgg11# myCNN = resnet50(pretrained=True,num_classes=7)# myCNN = vgg11(pretrained=False,num_classes=7)# myCNN = MyCNN(num_classes=7)# myCNN = MyCNNWithAttention(num_classes=7)# myCNN = MyCNNWithMultiScaleFusion(num_classes=7)myCNN = MyDenseCNN(num_classes=7)
parameters_info = paddle.summary(myCNN, (1, 3, 64, 64))print(parameters_info)

# 训练配置，并启动训练过程from paddle.vision.models import resnet50,vgg16# 设置设备device = paddle.set_device('gpu:0' if paddle.is_compiled_with_cuda() else 'cpu')def train(model):
    model.train()    #调用加载数据的函数
    #train_loader = load_data('train')
    opt = paddle.optimizer.SGD(learning_rate=0.001, parameters=model.parameters())
    EPOCH_NUM = 50
    acc_epoch=[]
    loss_epoch=[]    for epoch_id in range(EPOCH_NUM):
        acc_set = list()
        loss_set=[]        for batch_id, data in enumerate(train_loader()):            #准备数据，变得更加简洁
            #print(batch_id)
            images, labels = data
            images = paddle.to_tensor(images)
            labels = paddle.to_tensor(labels)
            labels = labels.unsqueeze(1)
            #print(images.shape)
            #print(labels.shape)

            #前向计算的过程
            predicts = model(images)            #print(predicts.shape)

            #计算损失，取一个批次样本损失的平均值
            loss = F.cross_entropy(predicts,labels)
            avg_loss = paddle.mean(loss)
            loss_set.append(avg_loss.numpy())

            acc=paddle.metric.accuracy(predicts,labels)
            acc_mean = paddle.mean(acc)
            acc_set.append(acc.numpy())
            #每训练了200批次的数据，打印下当前Loss的情况
            if batch_id % 10 == 0:                print("epoch: {}, batch: {}, loss is: {}".format(epoch_id, batch_id, avg_loss.numpy()))            #后向传播，更新参数的过程
            avg_loss.backward()
            opt.step()
            opt.clear_grad()
        print("acc is: {}".format(np.array(acc_set).mean()))
        acc_epoch.append(np.array(acc_set).mean())
        loss_epoch.append(np.array(loss_set).mean())    #print(predicts.shape)
    #print(labels.shape)
    #print(type(predits))
    #print(avg_loss)
    # 保存模型
    paddle.save(model.state_dict(), './mycnn.pdparams')# 创建模型           # model = resnet50(pretrained=True,num_classes=7)# model = MyCNN(num_classes=7)# model = MyCNNWithMultiScaleFusion(num_classes=7)# model = MyCNNWithAttention(num_classes=7)# model = vgg16(pretrained=True,num_classes=7)model = MyDenseCNN(num_classes=7)# 启动训练过程train(model)

print('测试数据集样本量：{}'.format(len(eval_dataset)))

def evaluation(model):
    print('start evaluation ......')    # 定义预测过程
    params_file_path = 'mycnn.pdparams'
    # 加载模型参数
    param_dict = paddle.load(params_file_path)
    model.load_dict(param_dict)

    model.eval()

    acc_set = []
    avg_loss_set = []    for batch_id, data in enumerate(eval_loader()):
        images, labels = data
        images = paddle.to_tensor(images)
        labels = paddle.to_tensor(labels)
        labels = labels.unsqueeze(1)
        predicts= model(images)
        loss = F.cross_entropy(input=predicts, label=labels)
        avg_loss = paddle.mean(loss)
        acc = paddle.metric.accuracy(predicts,labels)
        acc_set.append(float(acc.numpy()))
        avg_loss_set.append(float(avg_loss.numpy()))
    #计算多个batch的平均损失和准确率
    acc_val_mean = np.array(acc_set).mean()
    avg_loss_val_mean = np.array(avg_loss_set).mean()    print('loss={}, acc={}'.format(avg_loss_val_mean, acc_val_mean))# model = vgg16(pretrained=True,num_classes=7)# model = MyCNNWithMultiScaleFusion(num_classes=7)# model = MyCNNWithAttention(num_classes=7)model = MyDenseCNN(num_classes=7)# model = resnet50(pretrained=True,num_classes=7)# model = MyCNN(num_classes=7)evaluation(model)

# 样本映射LABEL_MAP = ['Sika_Deer','panda','Taiwan_Macaque','Chinese_Merganser','tiger','Wild_Camel','Yellow-bellied_Tragopan']for batch_id, data in enumerate(eval_loader()):
    images, labels_test = data
    images = paddle.to_tensor(images)
    predicts= model(images)    breakflag=0for idx in range(len(labels_test)):
    GT=labels_test[idx]
    PR=paddle.argmax(predicts,axis=1)[idx].numpy()
    GT=int(GT)
    PR=int(PR)    print("真实标签：",GT)    print("预测值：",PR)    print("真实标签：{}".format(LABEL_MAP[GT]))    print("预测值：{}".format(LABEL_MAP[PR]))    if GT==PR:
        flag+=1predict_acc=flag/len(labels_test)print('*****************************************')print(f'predict_acc = {predict_acc*100}%')

# 模型推理import matplotlib.pyplot as pltfrom PIL import Imageimport numpy as np
images_dir=['work/Chinese_Merganser.jpg','work/panda.jpg','work/Sika_Deer.jpg','work/Taiwan_Macaque.jpg','work/tiger.jpg','work/Wild_Came.jpg','work/Yellow-bellied_Tragopan.jpg']for i in images_dir:
    img = Image.open(i)
    plt.figure("Image") # 图像窗口名称
    plt.imshow(img)    if img.mode != 'RGB':
        img = img.convert('RGB')    # 转换成模型可读入的shape
    transforms = T.Compose([
        T.Resize((64, 64)),    # 图片缩放
        T.ToTensor(),          # 数据的格式转换和标准化、 HWC => CHW
        T.Normalize(mean=[0.485, 0.456, 0.406], std=[0.229, 0.224, 0.225])
        ])

    test_img=transforms(img)
    print(test_img.shape)
    test_img=test_img.unsqueeze(0)    print(test_img.shape)
    result=model(test_img)
    PR=paddle.argmax(result).numpy()    print(PR)    print("预测值：{}".format(LABEL_MAP[PR]))
    plt.show()
