无需拷贝：直接将JNI Direct Buffer数据上传至S3的优化方案

从JNI获取的Direct Buffer数据直接上传至S3，可以有效避免不必要的内存拷贝，提高程序性能。通常，从JNI获取的Direct Buffer需要先拷贝到JVM堆内存中，再进行上传操作。但这种方式会增加内存占用，并引入额外的拷贝开销。为了解决这个问题，我们可以利用jclouds库提供的ByteSource接口，自定义一个ByteSource实现，直接将Direct Buffer包装成输入流，从而避免了数据拷贝。

以下是具体实现步骤：

1. 创建自定义的ByteBufferByteSource类

   该类继承自ByteSource，并持有一个ByteBuffer对象。openStream()方法返回一个自定义的ByteBufferInputStream，用于从ByteBuffer中读取数据。

   import com.google.common.io.ByteSource;
   import java.io.IOException;
   import java.io.InputStream;
   import java.nio.BufferUnderflowException;
   import java.nio.ByteBuffer;

   import static com.google.common.base.Preconditions.checkNotNull;

   public class ByteBufferByteSource extends ByteSource {
       private final ByteBuffer buffer;

       public ByteBufferByteSource(ByteBuffer buffer) {
           this.buffer = checkNotNull(buffer);
       }

       @Override
       public InputStream openStream() {
           return new ByteBufferInputStream(buffer);
       }

       private static final class ByteBufferInputStream extends InputStream {
           private final ByteBuffer buffer;
           private boolean closed = false;

           ByteBufferInputStream(ByteBuffer buffer) {
               this.buffer = buffer;
           }

           @Override
           public synchronized int read() throws IOException {
               if (closed) {
                   throw new IOException("Stream already closed");
               }
               try {
                   return buffer.get() & 0xFF; // Important: convert byte to unsigned int
               } catch (BufferUnderflowException bue) {
                   return -1;
               }
           }

           @Override
           public synchronized int read(byte[] b, int off, int len) throws IOException {
               if (closed) {
                   throw new IOException("Stream already closed");
               }

               if (b == null) {
                   throw new NullPointerException();
               } else if (off < 0 || len < 0 || len > b.length - off) {
                   throw new IndexOutOfBoundsException();
               } else if (len == 0) {
                   return 0;
               }

               int available = buffer.remaining();
               if (available == 0) {
                   return -1;
               }

               int readLength = Math.min(len, available);
               buffer.get(b, off, readLength);
               return readLength;
           }

           @Override
           public void close() throws IOException {
               super.close();
               closed = true;
           }
       }
   }

   登录后复制

   注意事项:

   • ByteBufferInputStream 的 read() 方法中，需要将 buffer.get() 返回的 byte 值转换为 unsigned int，避免符号扩展导致数据错误。
   • 重写 read(byte[], int, int) 方法可以显著提高读取效率，避免单字节读取带来的性能瓶颈。
   • 需要处理流关闭状态，防止重复读取。

2. 使用自定义的ByteBufferByteSource上传数据

   在上传数据时，使用ByteBufferByteSource包装Direct Buffer，并将其作为payload传递给blobBuilder。



   ChatX翻译

   最实用、可靠的社交类实时翻译工具。 支持全球主流的20+款社交软件的聊天应用，全球200+语言随意切换。 让您彻底告别复制粘贴的翻译模式，与世界各地高效连接！

   77

   查看详情

   import org.jclouds.ContextBuilder;
   import org.jclouds.blobstore.BlobStore;
   import org.jclouds.blobstore.BlobStoreContext;
   import org.jclouds.blobstore.domain.Blob;
   import java.nio.ByteBuffer;

   public String uploadDirectBuffer(String container, String objectKey, ByteBuffer bb) {
       BlobStoreContext context = ContextBuilder.newBuilder("aws-s3") // 替换为你的S3 provider
               .credentials("YOUR_ACCESS_KEY", "YOUR_SECRET_KEY") // 替换为你的凭证
               .buildView(BlobStoreContext.class);
       BlobStore blobStore = context.getBlobStore();

       ByteBufferByteSource byteSource = new ByteBufferByteSource(bb);

       Blob blob = blobStore.blobBuilder(objectKey)
               .payload(byteSource)
               .contentLength(bb.capacity())
               .build();

       blobStore.putBlob(container, blob);
       context.close();
       return objectKey;
   }

   登录后复制

   注意事项:

   • 替换代码中的S3 provider和凭证信息。
   • 确保jclouds库已正确添加到项目中。

3. JNI代码示例

   #include <jni.h>
   #include <iostream>
   #include <sys/mman.h>
   #include <fcntl.h>
   #include <unistd.h>

   #define SHM_NAME "/my_shared_memory"
   #define SHM_SIZE 200 * 1024 * 1024 // 200MB

   JNIEXPORT jobject JNICALL Java_service_SharedMemoryJNIService_getDirectByteBuffer(JNIEnv *env, jclass clazz, jlong buf_addr, jint buf_len) {
       return env->NewDirectByteBuffer((void *)buf_addr, buf_len);
   }

   JNIEXPORT jlong JNICALL Java_service_SharedMemoryJNIService_createSharedMemory(JNIEnv *env, jclass clazz) {
       int shm_fd = shm_open(SHM_NAME, O_CREAT | O_RDWR, 0666);
       if (shm_fd == -1) {
           perror("shm_open");
           return -1;
       }

       if (ftruncate(shm_fd, SHM_SIZE) == -1) {
           perror("ftruncate");
           close(shm_fd);
           return -1;
       }

       void *ptr = mmap(0, SHM_SIZE, PROT_READ | PROT_WRITE, MAP_SHARED, shm_fd, 0);
       if (ptr == MAP_FAILED) {
           perror("mmap");
           close(shm_fd);
           return -1;
       }

       close(shm_fd); // No longer needed after mmap

       return (jlong)ptr;
   }

   JNIEXPORT void JNICALL Java_service_SharedMemoryJNIService_writeToSharedMemory(JNIEnv *env, jclass clazz, jlong buf_addr, jint data_size) {
       char *ptr = (char *)buf_addr;
       for (int i = 0; i < data_size; ++i) {
           ptr[i] = 'A' + (i % 26); // Example data
       }
   }

   JNIEXPORT void JNICALL Java_service_SharedMemoryJNIService_unmapSharedMemory(JNIEnv *env, jclass clazz, jlong buf_addr) {
       void *ptr = (void *)buf_addr;
       if (munmap(ptr, SHM_SIZE) == -1) {
           perror("munmap");
       }
   }

   JNIEXPORT void JNICALL Java_service_SharedMemoryJNIService_deleteSharedMemory(JNIEnv *env, jclass clazz) {
       if (shm_unlink(SHM_NAME) == -1) {
           perror("shm_unlink");
       }
   }

   登录后复制

4. Java代码示例

   package service;

   import java.nio.ByteBuffer;

   public class SharedMemoryJNIService {

       static {
           System.loadLibrary("sharedmemory"); // Load the sharedmemory library
       }

       public native ByteBuffer getDirectByteBuffer(long buf_addr, int buf_len);
       public native long createSharedMemory();
       public native void writeToSharedMemory(long buf_addr, int data_size);
       public native void unmapSharedMemory(long buf_addr);
       public native void deleteSharedMemory();

       public static void main(String[] args) {
           SharedMemoryJNIService service = new SharedMemoryJNIService();

           long sharedMemoryAddress = service.createSharedMemory();
           if (sharedMemoryAddress == -1) {
               System.err.println("Failed to create shared memory.");
               return;
           }

           int dataSize = 50 * 1024 * 1024; // 50MB
           service.writeToSharedMemory(sharedMemoryAddress, dataSize);

           ByteBuffer directBuffer = service.getDirectByteBuffer(sharedMemoryAddress, dataSize);

           // Example usage with the S3 uploader
           S3Uploader s3Uploader = new S3Uploader(); // Replace with your S3 uploader class
           String objectKey = "my-object";
           String bucketName = "my-bucket";

           try {
               String uploadedKey = s3Uploader.uploadDirectBuffer(bucketName, objectKey, directBuffer);
               System.out.println("Uploaded to S3: " + uploadedKey);
           } catch (Exception e) {
               System.err.println("Failed to upload to S3: " + e.getMessage());
               e.printStackTrace();
           } finally {
               service.unmapSharedMemory(sharedMemoryAddress);
               service.deleteSharedMemory();
           }
       }
   }

   登录后复制

   注意事项:

   • 确保正确配置JNI环境和动态链接库。
   • 替换S3Uploader为实际的S3上传类。

总结

通过自定义ByteSource，我们可以避免将Direct Buffer数据拷贝到JVM堆内存，从而实现高效的数据上传。这种方法不仅减少了内存占用，还降低了拷贝开销，提升了程序性能。在实际应用中，可以根据具体需求对ByteBufferInputStream进行优化，例如实现更高效的读取方式。
