本项目旨在通过应用神经网络技术，结合紫外差分光谱数据，实现对二氧化硫浓度的准确定量预测。项目将采用从不同环境中收集的紫外差分光谱数据，包括大气中SO2的光谱吸收特性以及环境参数（如温度、湿度等），作为输入特征。基于这些输入特征，将建立一个神经网络模型，通过对历史数据的学习和训练，实现对二氧化硫浓度的预测。
☞☞☞AI 智能聊天, 问答助手, AI 智能搜索, 免费无限量使用 DeepSeek R1 模型☜☜☜
项目计划包括以下步骤：
数据采集和准备：从不同环境中采集紫外差分光谱数据，包括SO2的光谱吸收特性以及环境参数。对采集到的数据进行处理和准备，包括数据清洗、特征提取和特征工程等。
模型选择和设计：根据项目需求，选择合适的神经网络模型，并进行模型的设计。可以考虑使用常见的神经网络模型，如多层感知器（MLP）、卷积神经网络（CNN）或循环神经网络（RNN）等。
模型训练和调优：使用采集到的紫外差分光谱数据，对选定的神经网络模型进行训练和调优。包括将数据集划分为训练集和验证集，进行模型参数的优化和调整，以获得最佳的预测性能。
模型评估和验证：通过对模型进行评估和验证，包括使用测试数据集进行性能测试，评估模型的预测准确性、稳定性和可靠性。根据评估结果进行模型的调整和优化。
结果解释和应用：根据训练好的神经网络模型，实现对二氧化硫的浓度预测
# 运行完一次记得注释掉!unzip /home/aistudio/data/data208645/Data.zip -d ./data
Archive: /home/aistudio/data/data208645/Data.zip creating: ./data/Data/ inflating: ./data/Data/test.xlsx inflating: ./data/Data/train.xlsx inflating: ./data/Data/val.xlsx
import pandas as pdimport paddleimport numpy as npfrom sklearn.model_selection import cross_val_score, train_test_splitimport matplotlib.pyplot as plt
train_data = pd.read_excel("./data/Data/train.xlsx", header=None)
val_data = pd.read_excel("./data/Data/val.xlsx", header=None)
test_data = pd.read_excel("./data/Data/test.xlsx", header=None)print("加载数据完成！")print("train_data:",train_data)print("val_data:",val_data)print("test_data:",test_data)/opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages/xlrd/xlsx.py:39: DeprecationWarning: defusedxml.cElementTree is deprecated, import from defusedxml.ElementTree instead. try: import defusedxml.cElementTree as ET
加载数据完成！
train_data: 0 1 2 3 4 5 6 \
0 -0.012270 -0.008444 -0.004375 -0.000184 0.003440 0.006620 0.008990
1 -0.025047 -0.015357 -0.005686 0.002572 0.008761 0.013994 0.018033
2 -0.037505 -0.021944 -0.007038 0.005147 0.014224 0.021056 0.026412
3 -0.061983 -0.034999 -0.010056 0.009798 0.023887 0.034412 0.042387
4 -0.073650 -0.041423 -0.011709 0.011549 0.027902 0.040159 0.049526
.. ... ... ... ... ... ... ...
164 -0.148829 -0.115722 -0.075014 -0.028676 0.019919 0.065222 0.104061
165 -0.160321 -0.122449 -0.077428 -0.027611 0.023061 0.070258 0.110567
166 -0.170898 -0.128527 -0.079606 -0.027007 0.026049 0.074729 0.116371
167 -0.194200 -0.142182 -0.084521 -0.025135 0.032484 0.084201 0.128401
168 -0.205352 -0.148857 -0.087424 -0.024942 0.034898 0.088087 0.133736
7 8 9 ... 414 415 416 \
0 0.011761 0.013728 0.014204 ... 0.000974 0.001178 0.001687
1 0.022009 0.024704 0.025219 ... 0.001391 0.001821 0.002151
2 0.031662 0.035359 0.035733 ... 0.002669 0.003190 0.003518
3 0.050285 0.055814 0.056690 ... 0.004162 0.005100 0.005648
4 0.059010 0.065689 0.067010 ... 0.005132 0.005943 0.006464
.. ... ... ... ... ... ... ...
164 0.139079 0.164084 0.175114 ... 0.006676 0.008426 0.009503
165 0.146746 0.173061 0.184654 ... 0.007423 0.009236 0.010182
166 0.153701 0.181050 0.193047 ... 0.007897 0.009787 0.010914
167 0.168198 0.197904 0.211459 ... 0.009296 0.011503 0.012656
168 0.175235 0.206353 0.220749 ... 0.009904 0.012182 0.013512
417 418 419 420 421 422 423
0 0.001411 0.000760 0.000105 -0.000448 -0.000898 -0.001340 1
1 0.002091 0.001451 0.000401 -0.000655 -0.001414 -0.002175 2
2 0.003363 0.001538 0.000307 -0.001323 -0.002451 -0.003273 3
3 0.005315 0.002817 0.000515 -0.001990 -0.004093 -0.005589 5
4 0.005909 0.002990 0.000467 -0.002356 -0.004476 -0.006186 6
.. ... ... ... ... ... ... ...
164 0.009424 0.006349 0.003002 -0.000789 -0.003904 -0.005904 11
165 0.009977 0.006880 0.003316 -0.000988 -0.004208 -0.006403 12
166 0.010501 0.007303 0.003547 -0.000943 -0.004642 -0.007005 13
167 0.012375 0.008722 0.004119 -0.001417 -0.005753 -0.008739 15
168 0.013215 0.009154 0.004446 -0.001490 -0.006323 -0.009596 16
[169 rows x 424 columns]
val_data: 0 1 2 3 4 5 6 \
0 -0.052783 -0.033933 -0.015029 0.002018 0.016323 0.028161 0.037847
1 -0.110682 -0.065505 -0.023264 0.011161 0.037215 0.057251 0.073270
2 -0.166297 -0.097069 -0.034448 0.015865 0.053162 0.081216 0.103936
3 -0.058965 -0.048355 -0.032819 -0.013860 0.007229 0.027811 0.045168
4 -0.116864 -0.079927 -0.041054 -0.004716 0.028120 0.056900 0.080591
5 -0.172479 -0.111491 -0.052238 -0.000012 0.044067 0.080866 0.111258
6 -0.064833 -0.062929 -0.051263 -0.030225 -0.002288 0.026767 0.051877
7 -0.122731 -0.094501 -0.059498 -0.021082 0.018603 0.055857 0.087301
8 -0.178346 -0.126065 -0.070682 -0.016378 0.034551 0.079822 0.117967
7 8 9 ... 414 415 416 417 \
0 0.046858 0.053088 0.054782 ... 0.003508 0.004392 0.005005 0.004664
1 0.088549 0.099801 0.103189 ... 0.006914 0.008079 0.008879 0.008336
2 0.125875 0.142550 0.148810 ... 0.010057 0.011853 0.012906 0.012040
3 0.060715 0.071836 0.076016 ... 0.002705 0.003693 0.004151 0.004271
4 0.102406 0.118550 0.124423 ... 0.006111 0.007379 0.008026 0.007943
5 0.139731 0.161299 0.170044 ... 0.009254 0.011154 0.012052 0.011647
6 0.073872 0.089537 0.096120 ... 0.002488 0.003486 0.004277 0.004285
7 0.115563 0.136250 0.144526 ... 0.005894 0.007173 0.008151 0.007957
8 0.152889 0.178999 0.190148 ... 0.009037 0.010947 0.012178 0.011661
418 419 420 421 422 423
0 0.001598 0.000032 -0.001605 -0.002903 -0.003765 4
1 0.004480 0.001232 -0.002686 -0.005762 -0.007993 9
2 0.007287 0.002562 -0.003217 -0.008333 -0.011865 14
3 0.001805 0.000592 -0.000741 -0.001296 -0.001838 4
4 0.004688 0.001792 -0.001822 -0.004155 -0.006066 9
5 0.007494 0.003122 -0.002353 -0.006726 -0.009938 14
6 0.002136 0.001090 -0.000121 -0.000501 -0.000710 4
7 0.005019 0.002291 -0.001202 -0.003360 -0.004938 9
8 0.007825 0.003621 -0.001733 -0.005931 -0.008810 14
[9 rows x 424 columns]
test_data: 0 1 2 3 4 5 6 \
0 -0.047434 -0.028410 -0.009918 0.005256 0.017354 0.027271 0.035861
1 -0.099031 -0.056289 -0.017596 0.013699 0.037585 0.055516 0.070344
2 -0.062197 -0.040211 -0.017950 0.001974 0.019550 0.034519 0.047329
3 -0.078246 -0.054903 -0.029160 -0.003992 0.019580 0.040875 0.059377
4 -0.100289 -0.076556 -0.046752 -0.014660 0.017760 0.048068 0.074909
5 -0.145121 -0.085051 -0.029667 0.015279 0.049730 0.076468 0.099693
6 -0.132055 -0.085548 -0.039095 0.002191 0.037861 0.067773 0.093635
7 -0.149218 -0.098919 -0.047757 -0.001335 0.039021 0.073859 0.104074
8 -0.181601 -0.126136 -0.067020 -0.011380 0.039078 0.084366 0.123608
7 8 9 ... 413 414 415 416 \
0 0.043041 0.047589 0.046583 ... 0.001697 0.002205 0.002398 0.002375
1 0.083724 0.092225 0.090622 ... 0.004748 0.006000 0.006237 0.006257
2 0.058283 0.065208 0.064650 ... 0.002485 0.003446 0.003920 0.004008
3 0.075338 0.085535 0.086047 ... 0.002587 0.003817 0.004476 0.004762
4 0.097708 0.112348 0.115042 ... 0.002646 0.003971 0.005033 0.005154
5 0.120608 0.133603 0.132983 ... 0.006556 0.008714 0.010171 0.010531
6 0.116255 0.130705 0.130851 ... 0.005689 0.007372 0.008379 0.008518
7 0.130882 0.148112 0.149885 ... 0.006297 0.008249 0.009537 0.009972
8 0.157677 0.180059 0.184107 ... 0.006566 0.009127 0.010725 0.011372
417 418 419 420 421 422
0 0.002135 0.003274 0.001698 -0.000402 -0.002128 -0.003881
1 0.005262 0.005548 0.002415 -0.001448 -0.004943 -0.008167
2 0.003807 0.003320 0.001366 -0.001075 -0.002917 -0.004651
3 0.004385 0.003837 0.001748 -0.000906 -0.003038 -0.004939
4 0.005022 0.004741 0.002553 -0.000666 -0.002847 -0.004768
5 0.009600 0.007677 0.003151 -0.002592 -0.007531 -0.011657
6 0.007794 0.006505 0.002671 -0.001938 -0.005730 -0.009093
7 0.009068 0.006826 0.002848 -0.002285 -0.006388 -0.009745
8 0.010681 0.008655 0.003997 -0.002015 -0.006974 -0.011061
[9 rows x 423 columns]class Regressor(paddle.nn.Layer):
# self代表类的实例自身
def __init__(self):
# 初始化父类中的一些参数
super(Regressor, self).__init__()
self.fc1 = paddle.nn.Linear(in_features=423, out_features=40)
self.fc2 = paddle.nn.Linear(in_features=40, out_features=20)
self.fc3 = paddle.nn.Linear(in_features=20, out_features=1)
self.relu = paddle.nn.ReLU()
# 网络的前向计算
def forward(self, inputs):
x = self.fc1(inputs)
x = self.relu(x)
x = self.fc2(x)
x = self.relu(x)
x = self.fc3(x)
x = self.relu(x) return x# 声明定义好的线性回归模型model = Regressor()# 开启模型训练模式model.train()# 定义优化算法，使用随机梯度下降SGDopt = paddle.optimizer.SGD(learning_rate=0.01, parameters=model.parameters())
EPOCH_NUM = 20 # 设置外层循环次数BATCH_SIZE =32 # 设置batch大小loss_train = []
loss_val = []
training_data = train_data.values.astype(np.float32)
val_data = val_data.values.astype(np.float32)# 定义外层循环for epoch_id in range(EPOCH_NUM): # 在每轮迭代开始之前，将训练数据的顺序随机的打乱
np.random.shuffle(training_data)
# 将训练数据进行拆分，每个batch包含10条数据
mini_batches = [training_data[k:k+BATCH_SIZE] for k in range(0, len(training_data), BATCH_SIZE)]
train_loss = [] for iter_id, mini_batch in enumerate(mini_batches): # 清空梯度变量，以备下一轮计算
opt.clear_grad()
x = np.array(mini_batch[:, :-1])
y = np.array(mini_batch[:, -1:])
# 将numpy数据转为飞桨动态图tensor的格式
features = paddle.to_tensor(x)
y = paddle.to_tensor(y)
# 前向计算
predicts = model(features)
# 计算损失
loss = paddle.nn.functional.l1_loss(predicts, label=y)
avg_loss = paddle.mean(loss)
train_loss.append(avg_loss.numpy())
# 反向传播，计算每层参数的梯度值
avg_loss.backward() # 更新参数，根据设置好的学习率迭代一步
opt.step()
mini_batches = [val_data[k:k+BATCH_SIZE] for k in range(0, len(val_data), BATCH_SIZE)]
val_loss = [] for iter_id, mini_batch in enumerate(mini_batches):
x = np.array(mini_batch[:, :-1])
y = np.array(mini_batch[:, -1:])
features = paddle.to_tensor(x)
y = paddle.to_tensor(y)
predicts = model(features)
loss = paddle.nn.functional.l1_loss(predicts, label=y)
avg_loss = paddle.mean(loss)
val_loss.append(avg_loss.numpy())
loss_train.append(np.mean(train_loss))
loss_val.append(np.mean(val_loss)) print(f'Epoch {epoch_id}, train MAE {np.mean(train_loss)}, val MAE {np.mean(val_loss)}')Epoch 0, train MAE 7.624902248382568, val MAE 8.33272647857666 Epoch 1, train MAE 7.206328868865967, val MAE 7.758003234863281 Epoch 2, train MAE 6.805103778839111, val MAE 6.986188888549805 Epoch 3, train MAE 6.075949192047119, val MAE 5.927742958068848 Epoch 4, train MAE 4.959263324737549, val MAE 4.292729377746582 Epoch 5, train MAE 3.2987468242645264, val MAE 2.087653875350952 Epoch 6, train MAE 1.5582104921340942, val MAE 0.9727618098258972 Epoch 7, train MAE 1.0503758192062378, val MAE 0.8623672723770142 Epoch 8, train MAE 0.9353340268135071, val MAE 0.7716569304466248 Epoch 9, train MAE 0.7899861931800842, val MAE 0.6565400958061218 Epoch 10, train MAE 0.6619129180908203, val MAE 0.5523999929428101 Epoch 11, train MAE 0.5093479156494141, val MAE 0.45839017629623413 Epoch 12, train MAE 0.4096043109893799, val MAE 0.3914491832256317 Epoch 13, train MAE 0.35209330916404724, val MAE 0.49695703387260437 Epoch 14, train MAE 0.3525097072124481, val MAE 0.2608330547809601 Epoch 15, train MAE 0.3310554325580597, val MAE 0.22819511592388153 Epoch 16, train MAE 0.28647658228874207, val MAE 0.5398315787315369 Epoch 17, train MAE 0.33176475763320923, val MAE 0.47069284319877625 Epoch 18, train MAE 0.382027268409729, val MAE 0.5325711965560913 Epoch 19, train MAE 0.37895312905311584, val MAE 0.175240620970726
# lossx = np.linspace(0, EPOCH_NUM+1, EPOCH_NUM)
plt.figure()
plt.plot(x, loss_train, color='red', linewidth=1.0, linestyle='--', label='line')
plt.plot(x, loss_val, color='y', linewidth=1.0, label='line')
plt.savefig('loss.png', dpi=600, bbox_inches='tight', transparent=False)
plt.legend(["train MAE", "val MAE"])
plt.title("Loss")
plt.xlabel('epoch_num')
plt.ylabel('loss value')/opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages/matplotlib/cbook/__init__.py:2349: DeprecationWarning: Using or importing the ABCs from 'collections' instead of from 'collections.abc' is deprecated, and in 3.8 it will stop working if isinstance(obj, collections.Iterator): /opt/conda/envs/python35-paddle120-env/lib/python3.7/site-packages/matplotlib/cbook/__init__.py:2366: DeprecationWarning: Using or importing the ABCs from 'collections' instead of from 'collections.abc' is deprecated, and in 3.8 it will stop working return list(data) if isinstance(data, collections.MappingView) else data
Text(55.8472,0.5,'loss value')
<Figure size 640x480 with 1 Axes>
model.eval()
test_data = paddle.to_tensor(test_data.values.astype(np.float32))
test_predict = model(test_data)
test_predict = test_predict.numpy().flatten()
test_predict = test_predict.round().astype(int)print("test_predict:",test_predict)test_predict: [ 4 9 5 6 7 13 11 12 14]
x = np.linspace(0, 10, 9)
Y_test = [4,9,5,6,7,14,12,13,15]
Y_test = np.array(Y_test)
predicted = test_predict
plt.figure()
plt.scatter(x, predicted, color='red') # 画点plt.scatter(x, Y_test, color='y') # 画点plt.plot(x, predicted, color='red', linewidth=1.0, linestyle='--', label='line')
plt.plot(x, Y_test, color='y', linewidth=1.0, label='line')
plt.savefig('result.png', dpi=600, bbox_inches='tight', transparent=False)
plt.legend(["predict value", "true value"])
plt.title("SO2")
plt.xlabel('X')
plt.ylabel('Absorption intensity')Text(47.0972,0.5,'Absorption intensity')
<Figure size 640x480 with 1 Axes>
以上就是基于神经网络结合紫外差分光谱的二氧化硫浓度定量预测的详细内容，更多请关注php中文网其它相关文章！
